Corrugator Belt Installation Guidance

How to install a new corrugator belt?

After new corrugator belts arrived, unloading and loading transport should pay attention, because cotton belt weight and volume are larger, if handled carelessly, the belt surface may easily be cut with a sharp tool.

1. When replacing the conveyor corrugator belt, first identify the installation direction, the joint with the surface of the canvas board is in contact with the face, the direction opposite the direction of the opening movement of the canvas and cardboard strip during installation, the installation location depends on the production line, in general, it is better in preheating the shelves near the cylinder rolls.

2 . After determining the direction, as long as the old interface runs to the right job position, removing the old belt to wear off, and the old with the new to wear off with one end connected with, start the main drive roller lead to the use of the old with the new production line around a week, running to the working position, removing the old belt to wear off emptied, then a new band with two pins connected to wear, you can test and pay attention to the slow run-time installation and commissioning, to avoid side collision or other accidents.

3. Thickness of the corrugator belt varies slight deviation using the first conveyor side must take a hot plate adjusted to the proper position gravity roller to adjust the friction between the belt and the cardboard, assuring paperboard's bonding quality.

4. When it starts running, you do not immediately put it into production and should be slow to run, to observe whether the deviation and the tightness of the corrugator belt are properly and timely adjustments until everything is normal before they go into production.

5. If the Corrugator conveyor belt due to the impact of the hot plate and pull the emergence of the phenomenon of deviation must be timely adjustments to avoid scratching worn with edge connectors and generally will stabilize within a month.

6. When packing, you must hold up the corrugator belt and paperboard, making it away from the hot plate surface drying, and preventing its surface from being damaged. Before installation, the installation process, or in case of any questions, please call us.
